Quick Assembled Container House
0102
product description
The appearance of this product is elegant and the container is designed to be 3 meters wide, 6 meters long and 2.8meters high. The column adopts 160mm wide-edge design.
The shape of the frame-type three-dimensional boxroom conforms to the aesthetics of engineering architecture. The frame adopts the classic spray-painting and baking process, and it is once colored and permanently retained, in line with EU export standards the main frame color can be customized at will, snow mountain white, zhongjian blue, construction work red, engineering ash and so on. The computer is color-matched, and the frame is spray-coated after pickling and phosphating. The anti-rust grade conforms to the national standard, and various colors are customized to highlight the cul-tural characteristics of the construction enterprise.
Configuration
| DEMENTIONS: | 6055 * 2435 * 2896mm 6055 * 3000 * 2896mm |
| Top Frame | roof color steel sheet , glass wool insulation , profiled steelroof beam , chipboard ceiling , steel cross member |
| Bottom Frame | PVC F loor , glass magnesium board , glass wool insulation , steel cross number , profiled steel beam , sub-floor color steel sheet |
| Corner Posts | 4 Posts |
| Exterior Steel Sheet | Flat/ Corrugated/ Orange Peel, 0.35-0.5mm thick |
| Wall panel | 50mm/75mm/100mm |
| Exterior Steel Sheet | Flat/ Corrugated/ Orange Peel, 0.35-0.5mm thick |
| Insulation | Glass wool/ Rock wool/ EPS/ Neopor / PU |
| Interior Steel Sheet | Flat/ Corrugated 0.35mm-0.5mm thickness |
| Color | RAL 9016(White),RAL 5015(Blue), Customized |
| Windows | UPVC Sliding Window |
| Door | 845*2035mm Steel door, 50mm thickness, |
| Electrical system | Customised to customer's national standards |
